Big Sports LED Display P 16 Synchronization Control with Video Processor

Name: Big Sports LED Display P 16 Synchronization Control with Video Processor
Brand: Dreamway
Price: 1 USD

Big Sports LED Display P 16 Synchronization Control with Video Processor Manufactures

Brand Name : Dreamway

Model Number : P16

Certification : CE,ROHS

Place of Origin : China

MOQ : negotiable

Price : negotiable

Payment Terms : T/T, Western Union

Supply Ability : 2000sq.m/Month

Delivery Time : 20 days after receiving the deposit

Packaging Details : Plywood case

Contact Now

Big Sports LED Display P 16 Synchronization Control with Video Processor

Quick Detail:

1. 1024 × 1024 mm cabinet size;
2. 64 × 64 dots per cabinet;
3. 4 × 4 pcs for each LED box;
4. More than 8,000 nits/sq.m;
5. OPTO / SAN'AN LED chip;
6. MBI5024 drive IC.

Detail Description:

The LED chip is composed with OPTO / SAN'AN, with MBI5024 IC, over 8,000 nits per square meter;
Each cabinet is 1024 by 1024 mm, about 53 kg, with 150 mm thickness;
Video processor with HDMI, VGA, DVI, S-VIDEO, COMPONENT input signals is equipped.

Application:

This stadium LED display screen is installed in the football stadium for video advertising, with high brightness and good display effect.

Specifications:

Pixel Pitch	16 mm
LED Composition	1R1G1B
LED Type	DIP546
LED Chip	OPTO / SAN'AN
Module Pixel	W 16 × H 16
Module Size	W 256 × H 256 mm
Cabinet Material	Steel waterproof cabinet
Driving Method	Static scan
Brightness	≥8000 nits/sq.m
Refresh Rate	≥1200 Hz
Driving IC	MBI5024
Resolution	3,906 dots/sq.m
MTBF	＞5,000 hours
LED Life Span	＞100,000 hours
Power Source	110V/60HZ and 220V/50HZ interchangeable
Operation Software	NovaStudio
Control Method	Synchronous control with video processor
Input Signal	DVI, VGA, COMPOSITE VIDEO, S-VIDEO, HDMI

Big Sports LED Display P 16 Synchronization Control with Video Processor
